Aspherical Micro-Optics for High-Resolution Imaging in Ultra-Compact Endoscope Systems
Endoscopy is a key element of modern minimally invasive diagnostics and therapy. Whether in gastroenterology, urology, ENT, or laparoscopic surgery, advanced endoscopes require precise, high-resolution imaging (>4K UHD) while continuing to shrink in size.
With ongoing miniaturization, increasing sensor resolutions, and the integration of additional functionalities (e.g., chip-on-tip, integrated illumination, fluorescence endoscopy), the demands on micro-optics are rising significantly. Each individual lens—particularly the front optics—has a decisive impact on sharpness, contrast, edge resolution, color correction, and illumination uniformity.
Optical Requirements for Modern Endoscopes
Modern endoscopes must deliver excellent imaging performance despite extremely compact dimensions. Optical components are subject to stringent technical requirements: precision, miniaturization, robustness, and fully reproducible manufacturing are essential to ensure reliable diagnostics and long-lasting systems.
INGENERIC Aspheres – High-Performance Optics for Modern Endoscopes
INGENERIC offers complex aspherical micro-optics (2–12 mm diameter) made from high-refractive-index glass, designed to meet demanding application requirements through precision and geometry. By integrating double-sided aspherical functional surfaces, numerical apertures >0.8, and highest form accuracy, optical designers benefit from maximum design flexibility in the development of endoscopic optical systems.
Maximum optical performance thanks to double-sided, aspheric surfaces with field-of-view angles up to 140°, the integration of precise functional and mounting surfaces, and customized AR coatings
High geometric flexibility and a wide range of variants achieved by combining convex and concave surfaces, with sub-micrometer-level dimensional accuracy, ensuring stable MTF performance across the entire field of view
High light throughput and efficiency enabled by high-quality, clean, and defect-free optical surfaces
More compact and higher-performance optical systems through reduced optical length, fewer elements, and increased space for LEDs, channels, or sensors
Product and Technology Highlights at A Glance
